Multiple bin groups
Daily and weekly storage totes that benefit from one continuous visible shelf run.
Wall Shelves
Heavy-Duty 2×8 Wall Shelf
Sixteen square feet of continuous wall storage for accessible bins, supplies, and long garage zones.
$700 installed
- Size
- Depth: 24 in; Support Height: 18–30 in; Width: 96 in
- Usable storage
- 16 sq ft of shelf deck
- Rated capacity
- Maximum evenly distributed load: 600 lb; Shelf Area: 16 sq ft
Available colors and finishes
- Black
- White
Images show the preferred configuration and available finish examples. The written quote confirms the exact product, finish, quantities, installed limit, and price before ordering.
Storage Job
What It Stores Well
This eight-foot shelf creates a long, visible storage run while keeping the floor clear. It is designed for customers with a continuous wall and enough two-foot depth to load and use the shelf without interfering with vehicles or circulation.
Project and car-care supplies
Boxed tools, detailing supplies, paper goods, and coolers organized by activity zone.
Family overflow
Items that need access more often than seasonal ceiling storage.
Strong matches
- Multiple bins
- Long clear walls
- Frequently used supplies
Know the limitations
- Needs eight feet of continuous wall
- Open shelving does not conceal or lock items
- Shelf loading and access must remain safe along the entire run
Technical Specifications
Measurements, Materials, and Limits
- Shelf width
- 96 in
- Shelf depth
- 24 in
- Support height
- Approximately 18–30 in
- Shelf area
- 16 sq ft
- Rated load
- Up to 600 lb evenly distributed
- Mounting
- Approved wood framing, masonry, or structural backing
Construction
Powder-coated steel frame and wire deck with aircraft-style support cables and a raised safety lip
Warranty
Limited lifetime product warranty or an approved equivalent; exact coverage is confirmed in the quote.
What is included
- Steel shelf frame and wire deck
- Support cables and wall brackets
- Approved mounting hardware for the confirmed wall
- Professional layout, mounting, and load review
Care
Inspect mounting points, cables, deck, and load distribution periodically. Wipe powder-coated surfaces with a soft damp cloth and mild cleaner.
Fit Check
Will It Fit Your Garage?
Final approval requires suitable framing or backing plus clearance from doors, windows, outlets, utilities, controls, vehicles, and walking paths.
- 1
A continuous 96 in clear wall run
- 2
A full 24 in projection clear of vehicles, doors, and walking paths
- 3
Verified structural framing, masonry, or backing
- 4
Clearance from windows, doors, electrical equipment, controls, plumbing, and utilities
Safety and Loading
Before Anything Is Installed
Keep loads evenly distributed and within the written installed limit.
Do not climb, sit, or hang from the shelf or support cables.
Keep incompatible or hazardous household products in appropriate labeled storage.
Product ratings assume the specified installation and loading conditions. Ace states the approved installed limit in writing after the site review.
Installed Packages
Where This Product Fits in a Complete Build
Product Questions
Frequently Asked Questions
Is one long shelf better than two short shelves?
A long shelf provides a continuous 16-square-foot deck. Two shorter shelves can work better around obstructions or separate activity zones.
Can it hold daily-use bins?
Yes, when installed at a comfortable reach height and the bin weight, shelf load, and loading path are appropriate.
Product Confirmation
The Specification Is the Promise
Ace selects storage by the dimensions, construction, capacity, finish, compatibility, warranty, and storage job shown here. If the preferred item is unavailable, we may propose an equivalent or better substitute. You receive the exact product, finish, quantities, limits, and installed price in writing before anything is ordered.
Plan the Whole Storage Layout
Match daily-use gear to the wall, tools and controlled storage to cabinets, and seasonal overflow to verified overhead space.
